La nueva Roadmachine 01 es más rápida que nunca y, al mismo tiempo, totalmente adecuada para cualquier superficie. La Roadmachine 01 THREE cuenta con cableado invisible, compartimento para almacenamiento integrado en el tubo diagonal y un conjunto de potencia ICS2 y manillar de carbono, y se complementa con el grupo SRAM Force AXS y el juego de ruedas de carbono CRD-321 con cubiertas de carretera de 30 mm.
Tecnología
Almacenamiento en el tubo diagonal con portabidones integrados
Potencia ICS2
Luz trasera integrada
TCC Endurance
Descripción técnica
Cuadro
Cuadro:
Roadmachine 01 Premium Carbon with Tuned Compliance Concept Endurance | ICS Technology Stealth Cable Routing | Integrated Downtube Storage | Stealth Dropout Design | 12 x 142mm Thru-Axle
Horquilla:
Roadmachine 01 Premium Carbon with Tuned Compliance Concept Endurance | Flat Steerer Fork | Stealth Dropout Design | Internal Cable Routing | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Potencia:
BMC ICS2 | Integrated Cockpit System Technology
Manillar:
Easton EC70 SL Carbon or Easton EC90 SLX Carbon
Seat
Tija de Sillín:
Roadmachine 01 Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible
Sillín:
Fizik Argo Tempo R5 | 150mm
Transmisión
Platos y Bielas:
SRAM Force
Platos:
46-33T
Cassette:
SRAM Force XG-1270
Tamaño del cassette:
10-36T
Cadena:
SRAM Apex
Desviador Delantero:
SRAM Force eTap AXS
Cambio Trasero:
SRAM Force eTap AXS
Manetas de Cambio:
SRAM Force eTap AXS
Marchas:
2 x 12
Pedalier:
PF86 Bottom Bracket
Frenos
Pinzas de Freno:
SRAM Force eTap AXS
Discos:
SRAM Centerline X
Tamaño del disco:
160 / 160mm
Ruedas
Llantas:
CRD-321 SL Carbon | Tubeless Ready | 35mm
Bujes:
CRD-321 SL
Neumáticos:
Vittoria Corsa N.EXT G2.0 | TLR (Tubeless Ready) | 30mm
Información Tubeless:
Tubeless Ready Rims | Tubetype Tires
Accesorios
Integrated Rear Light 20
| Roadmachine Bottle Cages | Storage Pouch
Información adicional
Paso de rueda:
40mm
Peso sin pedales:
7.8 Kg
Clasificación ASTM:
Level 2
Límite de peso del sistema:
110kg
| Size | 47 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Rider Height | <160 | 158-174 | 172-180 | 178-186 | 184-192 | >190 |
| Reach | 370 | 379 | 383 | 388 | 393 | 398 |
| Stack | 525 | 550 | 570 | 595 | 620 | 645 |
| Bar Drop | 127 | 127 | 127 | 127 | 127 | 127 |
| Bar Reach | 67 | 67 | 67 | 67 | 67 | 67 |
| Bar Width | 400 | 420 | 420 | 420 | 420 | 420 |
| BB Drop | 75 | 75 | 75 | 75 | 75 | 75 |
| Crank Length | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
| Fork Length | 379 | 379 | 379 | 379 | 379 | 379 |
| Fork Rake | 50 | 50 | 45 | 45 | 45 | 45 |
| Front Center | 579 | 596 | 594 | 607 | 620 | 633 |
| Head Tube | 112 | 138 | 154 | 181 | 207 | 233 |
| Head Tube Angle | 71.4 | 71.4 | 72.2 | 72.2 | 72.2 | 72.2 |
| Rear Center | 415 | 415 | 415 | 415 | 415 | 415 |
| Seat Angle | 74.2 | 74.2 | 74.2 | 74.2 | 74.2 | 74.2 |
| Seat Tube | 414 | 461 | 488 | 508 | 529 | 550 |
| Seatpost Length | 330 | 380 | 380 | 380 | 380 | 430 |
| Seatpost Offset | 15 | 15 | 15 | 15 | 15 | 15 |
| Standover Height | 726 | 762 | 786 | 807 | 828 | 849 |
| Stem Angle | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 |
| Stem Length | 90 | 100 | 100 | 110 | 110 | 120 |
| Top Tube | 520 | 537 | 546 | 559 | 571 | 581 |
| Trail | 63 | 63 | 63 | 63 | 63 | 63 |
| Wheelbase | 982 | 1000 | 997 | 1010 | 1023 | 1036 |
