BMC-23-10611-015

Teammachine SLR THREE

SPARKLING BLUE / BRUSHED ALLOY

Transmisión Shimano Ultegra Di2
Juego de ruedas XRD-522
Cableado integrado y tija de sillín de carbono de tipo “D”

Precio habitualCHF 5,699.00
/
Impuesto incluido.

SKU: 30002332
Talla

Teammachine SLR THREE

Piezas y accesorios

El legendario rendimiento de la Teammachine SLR en un paquete ampliamente accesible. Diseñada con la tecnología TCC Race en el cuadro y la horquilla de carbono, la Teammachine SLR es una bicicleta de carretera que conoce perfectamente el significado de alto rendimiento, y cuenta con punteras Stealth y cableado interno. Equipada con el grupo Shimano Ultegra Di2 de 12 velocidades, la Teammachine SLR THREE tiene una gran relación calidad-precio, con ruedas XRD-522 preparadas para tubeless y un manillar y potencia convencionales que completan el montaje.

Tecnología

Descripción técnica

Cuadro

Cuadro:
Teammachine SLR Carbon with Aerocore Design | Stealth Dropout Design | TCC Race Compliance Level | PF86 Bottom Bracket | Flat Mount Disc | 12x142mm Thru-Axle | Optimized for Aerocore Bottle Cages

Horquilla:
Teammachine SLR Carbon | TCC Race Compliance Level | Internal Cable Routing | Flat Mount Disc | Stealth Dropout Design | 12x100mm Thru-Axle

Cockpit

Manillar:
BMC RAB 02 - Ergo Top Shape - Compact Bend

Potencia:
BMC RSM01

Tija de Sillín:
Teammachine SLR Carbon D-Shaped Seatpost

Sillín:
Fizik Antares R7

Transmisión

Marchas:
2x12

Platos y Bielas:
SHIMANO Ultegra FC-R8100 12spd 52-36T

Cassette:
SHIMANO Ultegra CS-R8100 12spd 11-30T

Cadena:
SHIMANO Ultegra CN-M8100 12spd

Desviador Delantero:
SHIMANO Ultegra Di2 FD-R8150 12spd

Cambio Trasero:
SHIMANO Ultegra Di2 RD-R8150 12spd

Manetas de Cambio:
SHIMANO Ultegra Di2 ST-R8170 12spd

Frenos

Pinzas de Freno:
SHIMANO Ultegra BR-R8170

Discos:
SHIMANO RT-MT800 160 / 140mm

Ruedas

Llantas:
XRD-522 - Tubeless Ready - 25mm

Bujes:
XRD-522

Neumáticos:
Vittoria Rubino - 25mm

Información Tubeless:
Tubeless Ready Rims / Tubeless Tires

Información adicional

Anchura Máx. de Neumático:
30mm (Measured Width)

Clasificación ASTM:
Level 1

Límite de Peso:
110 Kg

Size475154565861
Rider Height<166166-174172-180178-186184-192>190
Reach367377386392401409
Stack506530550565584608
Bar Drop125125125125125125
Bar Reach707070707070
Bar Rise
Bar Sweep
Bar Width400420420420420440
Base Bar Drop Flat Cockpit
Base Bar Drop V-Cockpit
Base Bar Reach Flat Cockpit
Base Bar Reach V-Cockpit
BB Drop696969696969
BB Drop (SLACK)
BB Drop (STEEP)
BB Height (SLACK)
BB Height (STEEP)
Chainstay
Crank Length170170172.5172.5175175
LT | BB Drop (SLACK)
LT | BB Drop (STEEP)
LT | BB Height (SLACK)
LT | BB Height (STEEP)
LT | Chainstay
LT | Fork Length
LT | Fork Rake
LT | Frame Size
LT | Front Center (SLACK)
LT | Front Center (STEEP)
LT | Head Tube
LT | HT Angle (SLACK)
LT | HT Angle (STEEP)
LT | Reach (SLACK)
LT | Reach (STEEP)
LT | Rider Height
LT | Seat Tube
LT | ST Angle @750mm Saddle Height (SLACK)
LT | ST Angle @750mm Saddle Height (STEEP)
LT | ST Angle Actual (SLACK)
LT | ST Angle Actual (STEEP)
LT | ST Angle Effective (SLACK)
LT | ST Angle Effective (STEEP)
LT | Stack (SLACK)
LT | Stack (STEEP)
LT | Stand Over Height (80 in Front of BB)
LT | Stand Over Height (Lowest Point)
LT | Top Tube (SLACK)
LT | Top Tube (STEEP)
LT | Wheelbase (SLACK)
LT | Wheelbase (STEEP)
ST | BB Drop (SLACK)
ST | BB Drop (STEEP)
ST | BB Height (STACK)
ST | BB Height (STEEP)
ST | Chainstay
ST | Fork Length
ST | Fork Rake
ST | Frame Size
ST | Front Center (SLACK)
ST | Front Center (STEEP)
ST | Head Tube
ST | HT Angle (SLACK)
ST | HT Angle (STEEP)
ST | Reach (SLACK)
ST | Reach (STEEP)
ST | Rider Height
ST | Seat Tube
ST | ST Angle @750mm Saddle Height (SLACK)
ST | ST Angle @750mm Saddle Height (STEEP)
ST | ST Angle Actual (SLACK)
ST | ST Angle Actual (STEEP)
ST | ST Angle Effective (SLACK)
ST | ST Angle Effective (STEEP)
ST | Stack (SLACK)
ST | Stack (STEEP)
ST | Stand Over Height (80 in Front of BB)
ST | Stand Over Height (Lowest Point)
ST | Top Tube (SLACK)
ST | Top Tube (STEEP)
ST | Wheelbase (SLACK)
ST | Wheelbase (STEEP)
Fork Length368368368368368368
Fork Rake484843434343
Frame Size
Front Center568586589599614630
Front Center (SLACK)
Front Center (STEEP)
Head Tube110130145165184210
Head Tube Angle71.571.572.372.372.372.3
HT Angle (SLACK)
HT Angle (STEEP)
Pad Reach Flat Cockpit
Pad Reach V-Cockpit
Pad Stack Flat Cockpit
Pad Stack V-Cockpit
Reach (SLACK)
Reach (STEEP)
Rear Center410410410410410410
Saddle Height Range
Seat Angle73.573.573.573.573.573.5
Seat Tube423468504524545574
Seatpost Drop
Seatpost Length330380380380380380
Seatpost Offset151515151515
ST Angle @750mm Saddle Height (SLACK)
ST Angle @750mm Saddle Height (STEEP)
ST Angle Actual (SLACK)
ST Angle Actual (STEEP)
ST Angle Effective (SLACK)
ST Angle Effective (STEEP)
Stack (SLACK)
Stack (STEEP)
Stand Over Height (80 in Front of BB)
Stand Over Height (Lowest Point)
Standover Height717752779797817843
Stem Angle±8±8±8±8±8±8
Stem Length9090100110110120
Top Tube517534549559574589
Top Tube (SLACK)
Top Tube (STEEP)
Trail636363636363
Wheelbase968986989100010151030
Wheelbase (SLACK)
Wheelbase (STEEP)
