Kaius 01 LTD | BMC | bikes | Gravel, Gravel | Performance

Peacock Spider

SRAM RED XPLR eTAP AXS Drivetrain
ZIPP 303 Firecrest Wheelset
ICS Carbon Evo One-Piece Cockpit

CHF 11,999.00

SKU: 30005302

Size —

Low stock - 4 items left
Inventory on the way

Compatible Parts & Accessories

Shipped to your local bike shop

Check for availability within our Retailer Network

[{"id":40926156390479,"title":"47","option1":"47","option2":null,"option3":null,"sku":"30005302","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Kaius 01 LTD - 47","public_title":"47","options":["47"],"price":1199900,"weight":15000,"compare_at_price":0,"inventory_quantity":4,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630906508831","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40926156456015,"title":"51","option1":"51","option2":null,"option3":null,"sku":"30005303","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Kaius 01 LTD - 51","public_title":"51","options":["51"],"price":1199900,"weight":15000,"compare_at_price":0,"inventory_quantity":4,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630906508824","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40926156488783,"title":"54","option1":"54","option2":null,"option3":null,"sku":"30005304","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Kaius 01 LTD - 54","public_title":"54","options":["54"],"price":1199900,"weight":15000,"compare_at_price":0,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630906508817","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40926156554319,"title":"56","option1":"56","option2":null,"option3":null,"sku":"30005305","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Kaius 01 LTD - 56","public_title":"56","options":["56"],"price":1199900,"weight":15000,"compare_at_price":0,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630906508800","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40926156587087,"title":"58","option1":"58","option2":null,"option3":null,"sku":"30005306","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Kaius 01 LTD - 58","public_title":"58","options":["58"],"price":1199900,"weight":15000,"compare_at_price":0,"inventory_quantity":2,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630906508794","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40926156619855,"title":"61","option1":"61","option2":null,"option3":null,"sku":"30005307","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Kaius 01 LTD - 61","public_title":"61","options":["61"],"price":1199900,"weight":15000,"compare_at_price":0,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630906508787","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Watch Now

Kaius is a premium carbon gravel bike built to be your elite race companion for all terrains. The unprecedented carbon layup and gravel-specific geometry ensure the perfect balance of stiffness, lightweight, and compliance for optimal traction on loose surfaces, front-end stability, and unmatched climbing prowess. Harnessing the precision and performance of our renowned leading road technologies, Kaius is a race machine tuned to the gravel wavelength with the engineered Kaius fork, our ICS Carbon Evo Cockpit, TCC Race compliance, compatibility with 1x and 2x drivetrains and up to 44 mm of tire clearance.

Technology

Speed Unbound

The innovative premium carbon layup uses ultra high-module fibres for unmatched stiffness resulting in maximum power transfer and minimal weight. Kaius boasts our Tuned Compliance Concept Race Technology for a comfortable ride on rough surfaces.

Race-ready Gravel Geometry

Kaius was built with one purpose: to be fast on gravel roads. That is why we produced a gravel-specific frame with a longer reach shifting the front wheel forward to improve stability and increase traction on loose surfaces.

ICS Carbon Evo Cockpit

Where integration meets highly functional comfort. The next-gen ICS Carbon Evo cockpit has a revised form for better fit, and signature BMC comfort and control. Super lightweight, check. Stiff, check. 8° flare for added control, check.

Aerocore Design

Kaius comes in at the highest level of functional integration with our Aerocore design. This evolved solution integrates the bottle cages into the frame to optimize aerodynamic performance.

Technical Overview

Frameset

Cockpit

Handlebar:
ICS Carbon Evo | One Piece Full Carbon Cockpit

Seat

Seatpost:
Kaius 01 Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible

Saddle:
Fizik Vento Argo R1 | 140mm

Drivetrain

Crankset:
SRAM RED AXS 1 DUB WIDE

Chainrings:
42T

Power Meter:
SRAM RED AXS 1 DUB WIDE Power Meter

Cassette:
SRAM XPLR XG-1271

Cassette Size:
10-44T

Chain:
SRAM RED

Rear Derailleur:
SRAM RED XPLR AXS (RD-RED-1E-E1)

Shifters:
SRAM RED eTap AXS HRD

Gears:
1 x 12

Bottom Bracket:
PF86 Bottom Bracket

Brakes

Brake Levers / Calipers:
SRAM RED eTap AXS HRD

Rotors:
SRAM Centerline | Centerlock

Rotor Size (F/R):
160 / 160mm

Wheels

Rims:
Zipp 303 Firecrest

Hubs (F/R):
Zipp 303 Firecrest

Tires:
Pirelli Cinturato Gravel H | 40mm

Tubeless Information:
Tubeless Ready Rims | Tubetype Tires

Additional Information

Tire Clearance:
44mm

ASTM Classification:
Level 2

System Weight Limit:
120kg

Size	47	51	54	56	58	61
Rider Height	<166	166-174	172-180	178-186	184-192	>190
Reach	390	397	401	405	410	414
Stack	510	530	550	570	595	620
Bar Drop	128	128	128	128	128	128
Bar Reach	68	68	68	68	68	68
Bar Width	400 / 436	400 / 436	400 / 436	400 / 436	400 / 436	400 / 436
BB Drop	80	80	80	80	80	80
Crank Length	170	170	172.5	172.5	175	175
Fork Length	387	387	387	387	387	387
Fork Rake	50	50	45	45	45	45
Front Center	596	610	608	619	632	644
Head Tube	85	106	123	144	170	196
Head Tube Angle	71	71	72	72	72	72
Rear Center	420	420	420	420	420	420
Seat Angle	73	73	73	73	73	73
Seat Tube	428	452	468	493	513	533
Seatpost Length	280	320	360	360	400	400
Seatpost Offset	15	15	15	15	15	15
Standover Height	684	722	756	780	798	818
Stem Angle	-7.5	-7.5	-7.5	-7.5	-7.5	-7.5
Stem Length	80	90	90	100	100	110
Top Tube	546	559	569	579	592	604
Trail	68	68	68	68	68	68
Wheelbase	1003	1017	1015	1026	1039	1051
